IntelliVue X3

Patient monitor

Find similar products

The Philips IntelliVue X3 is a compact, dual-purpose, transport patient monitor featuring intuitive smartphone-style operation and offering a scalable set of clinical measurements.

Contact & support

Documentation

Brochure (1)

Brochure

Customer story (1)

Customer story

Product overview (1)

Product overview

Brochure (1)

Brochure

Customer story (1)

Customer story

See all documentation

Brochure (1)

Brochure

Customer story (1)

Customer story

Product overview (1)

Product overview

Specifications

Display
Display
Description
  • Active matrix color LCD display with capacitive multi-touch screen
Size
  • 15.5cm (6.1in)
Resolution
  • 1024 x 480
Number of measurement waves
  • up to 5 (or 12 ECG waves)
Supported screen orientations
  • 0° / 90° / 180°
Screen
  • Antimicrobial Corning® Gorilla® Glass
Measurements
Measurements
Basic
  • ECG
  • SpO₂ (Philips FAST-SpO₂, Nellcor OxiMax SpO₂, Masimo rainbow SET SpO₂)
  • Respiration
  • NiBP
Weight
  • 1.4 kg (3.1 lb) incl. options, battery pack and handle
Size (with handle)
  • 249 x 97 x 111 mm (9.8. x 3.8 x 4.4 in)
Optional:
  • 2 invasive pressures, CO₂, second SpO₂
With IntelliVue measurement extensions
  • Up to 4 invasive pressures and 2 temperatures;
  • Cardiac output (right-heart and PiCCO);
  • Covidien Microstream CO₂;
  • Repironics mainstream CO₂ or LoFlo sidestream CO₂
Battery
Battery
Capacity
  • 5 hours (basic configuration)[⁴]
Ruggedness
Ruggedness
Disinfection
  • Highly disinfectant-resistant surface materials
Mechanical ruggedness
  • 7M3
Display
Display
Description
  • Active matrix color LCD display with capacitive multi-touch screen
Size
  • 15.5cm (6.1in)
Measurements
Measurements
Basic
  • ECG
  • SpO₂ (Philips FAST-SpO₂, Nellcor OxiMax SpO₂, Masimo rainbow SET SpO₂)
  • Respiration
  • NiBP
Weight
  • 1.4 kg (3.1 lb) incl. options, battery pack and handle
See all specifications
Display
Display
Description
  • Active matrix color LCD display with capacitive multi-touch screen
Size
  • 15.5cm (6.1in)
Resolution
  • 1024 x 480
Number of measurement waves
  • up to 5 (or 12 ECG waves)
Supported screen orientations
  • 0° / 90° / 180°
Screen
  • Antimicrobial Corning® Gorilla® Glass
Measurements
Measurements
Basic
  • ECG
  • SpO₂ (Philips FAST-SpO₂, Nellcor OxiMax SpO₂, Masimo rainbow SET SpO₂)
  • Respiration
  • NiBP
Weight
  • 1.4 kg (3.1 lb) incl. options, battery pack and handle
Size (with handle)
  • 249 x 97 x 111 mm (9.8. x 3.8 x 4.4 in)
Optional:
  • 2 invasive pressures, CO₂, second SpO₂
With IntelliVue measurement extensions
  • Up to 4 invasive pressures and 2 temperatures;
  • Cardiac output (right-heart and PiCCO);
  • Covidien Microstream CO₂;
  • Repironics mainstream CO₂ or LoFlo sidestream CO₂
Battery
Battery
Capacity
  • 5 hours (basic configuration)[⁴]
Ruggedness
Ruggedness
Disinfection
  • Highly disinfectant-resistant surface materials
Mechanical ruggedness
  • 7M3
  • ¹ Provides 12 years of backwards compatibility with IntelliVue patient monitoring hardware (may require software upgrade). Over 6 years of backwards compatibility with Patient Information Center hardware (may require software upgrade).
  • ² See the IntelliVue X3 Instructions for Use for a complete list of recommended agents.
  • ³ Corning and Gorilla are registered trademarks of Corning Incorporated. Antimicrobial Corning Gorilla Glass does not protect users or provide any direct or implied health-benefit.
  • ⁴ ECG/Resp, FAST SpO₂, NBP every 15min, Brightness set to Optimum
  • Product features may not be available in all geographies. Please check with your Philips representative for complete portfolio availability.
