Other items in the box
- AC Power Cord
- Batteries for remote control
- Quick start guide
- Remote Control
- RS232 cable
Signage Solutions H-Line Display
55BDL3202H/00
- -{discount-value}
Signage Solutions H-Line Display
55BDL3202H/00Turn heads
Stay visible day and night with Philips H-Line Full HD Display. Astonishing clarity and contrast make this a perfect solution for busy areas that are subject to high ambient light. From airports to shopping centres.
Unfortunately this product is no longer available
This product qualifies for VAT relief
If you're eligible for VAT relief on medical devices, you can claim it on this product. The VAT amount will be deducted from the price shown above. Look for full details in your shopping basket.
Signage Solutions H-Line Display
Turn heads
Stay visible day and night with Philips H-Line Full HD Display. Astonishing clarity and contrast make this a perfect solution for busy areas that are subject to high ambient light. From airports to shopping centres.
Turn heads
Stay visible day and night with Philips H-Line Full HD Display. Astonishing clarity and contrast make this a perfect solution for busy areas that are subject to high ambient light. From airports to shopping centres.
Unfortunately this product is no longer available
This product qualifies for VAT relief
If you're eligible for VAT relief on medical devices, you can claim it on this product. The VAT amount will be deducted from the price shown above. Look for full details in your shopping basket.
Signage Solutions H-Line Display
Turn heads
Stay visible day and night with Philips H-Line Full HD Display. Astonishing clarity and contrast make this a perfect solution for busy areas that are subject to high ambient light. From airports to shopping centres.
Similar products
See all H-Line series
Operate, monitor and maintain with CMND & Control
Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.
CMND & Create. Develop and launch your own content
Take control of your content with CMND & Create. A drag-and-drop interface makes it simple to publish your own content-whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure your stills, text, and video will be up and running in no time.
FailOver ensures content is always playing
From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.
OPS slot allows for PC embedding without cabling
Integrate a full-power PC or Android-powered CRD50 module directly into your Philips Professional Display. The OPS slot contains all the connections you need to run your slot-in solution, including a power supply.
Add Android processing power with an optional CRD50 module
Embed an Android System-on-Chip (SoC) in your Philips Professional Display. The optional CRD50 module is an OPS device that enables Android processing power without the need for cables. Simply slide into the OPS slot, which contains all the connections needed to run the module (including power supply).
Remote system management through CMND
Take control of your Philips Professional Display network. CMND lets you manage, update, maintain, and play via one easy-to-use interface. From installation to daily operation.
High brightness (2500 cd/m2). Suited to semi-outdoor use
Make a big impact in bright or semi-outdoor locations. This ultra-high-brightness 2500 cd/m2 display is perfect for attracting attention in large, busy areas that are subject to high ambient light.
Technical Specifications
-
Picture/Display
- Diagonal screen size (inch)
- 54.6 inch
- Diagonal screen size (metric)
- 138.7 cm
- Optimum resolution
- 1920 x 1080 @ 60Hz
- Brightness
- 2500 cd/m²
- Contrast ratio (typical)
- 5000:1
- Dynamic contrast ratio
- 500,000:1
- Aspect ratio
- 16:9
- Response time (typical)
- 6 ms
- Pixel pitch
- 0.63 x 0.63 mm
- Display colors
- 16.7 M (8 bits)
- Viewing angle (horizontal)
- 178 degree
- Viewing angle (vertical)
- 178 degree
- Panel resolution
- 1920x1080p
-
Connectivity
- Video input
-
- Composite (Share component Y)
- Display Port1.2 (x1)
- DVI-D (x1)
- HDMI 1.4 (x2)
- VGA (Analog D-Sub) (x1)
- Component BNC (x3)
-
- Video output
-
- DisplayPort 1.2 (x1)
- DVI-I (x1)
-
- Audio input
-
- 3.5 mm jack
- Audio Left/Right (RCA)
-
- Audio output
- Audio Left/Right (RCA)
- External control
-
- RS232C (in/out) 2.5 mm jack
- RJ45
- IR (in/out) 3.5 mm jack
-
- Other connections
-
- OPS
- USB
-
-
Dimensions
- Bezel width
- 15.80mm (Even Bezel)
- Set Width
- 1243.2 mm
- Set Height
- 714.0 mm
- Set Depth
- 137.9 mm
- Set Width (inch)
- 48.9 inch
- Set Height (inch)
- 28.1 inch
- Set Depth (inch)
- 5.43 inch
- Wall Mount
- 400 x 400 mm, M6
- Product weight
- 32.2 kg
- Product weight (lb)
- 70.99 lb
- Smart insert height
- 200 mm
- Smart insert width
- 100 mm
- Smart Insert mount
- 100 x 100mm,100 x 200mm
-
Convenience
- Placement
-
- Landscape
- Portrait
-
- Network controllable
-
- RS232
- HDMI (One Wire)
- LAN (RJ45)
-
- Signal loop through
-
- RS232
- IR Loopthrough
- DisplayPort
- RJ45
-
- Energy saving functions
- Smart Power
- Remote control signal
- Lockable
- Keyboard control
-
- Hidden
- Lockable
-
- Ease of installation
-
- Smart Insert
- Carrying Handles
-
- Other convenience
- Carrying handles
- Screen saving functions
- Pixel Shift, Low Brightness
- Picture performance
- Advanced color control
-
Power
- Consumption (Typical)
- 280 W
- Standby power consumption
- <0.5W
- Consumption (Max)
- 508 W
-
Sound
- Built-in speakers
- 2 x 10W RMS
-
Operating conditions
- Temperature range (operation)
- 0 ~ 40 °C
- Temperature range (storage)
- -20 ~ 60 °C
- Relative humidity
- 20 ~ 80(operation),5 - 95% (storage) %
- MTBF
- 50,000 hour(s)
- Altitude
- 0 ~ 3000 m
-
Accessories
- Included accessories
-
- AC Power Cord
- Batteries for remote control
- Quick start guide
- Remote Control
- RS232 cable
-
- Included Accessories
-
- RS232 daisy-chain cable
- Edge Alignment Kit (1) -1 pcs
- Edge Alignment Kit (2) - 2 pcs
- Philips logo (x1)
- Thumbscrew (8pcs)
-
-
Miscellaneous
- On-Screen Display Languages
-
- English
- French
- German
- Italian
- Polish
- Russian
- Spanish
- Turkish
- Simplified Chinese
- Traditional Chinese
- Arabic
- Japanese
- Portuguese
- Dutch
-
- Regulatory approvals
-
- CB
- CE
- UL/cUL
- EAC
- EMF
- FCC, Class A
- PSB
- PSE
- VCCI
-
- Warranty
- 3 year warranty
-
Multimedia Applications
- USB Playback Audio
-
- AAC
- LPCM
- M4A
- MP3
- WMA
-
- USB Playback Picture
-
- BMP
- GIF
- JPEG
- PNG
-
- USB Playback Video
-
- ISM
- M2TS
- M4V
- Manifest
- MK3D
- MKV
- MP4
- MPD
- MPEG
- MPG
- MTS
- TS
- TTS
- VOB
-
-
Supported Display Resolution
- Computer formats
-
- 1024 x 768, 60, 75Hz
- 1280 x 1024, 60Hz
- 1280 x 768, 60Hz
- 1280 x 800, 60Hz
- 1360 x 768, 60Hz
- 1600 x 1200, 60Hz
- 1920 x 1080, 60Hz
- 640 x 480, 60, 72, 75Hz
- 720 x 400, 70Hz
- 800 x 600, 60, 75Hz
-
- Video formats
-
- 1080i, 50, 60Hz
- 1080p, 50, 60Hz
- 480i, 60Hz
- 480p, 60Hz
- 576i, 50Hz
- 576p, 50Hz
- 720p, 50, 60Hz
-
